LOAD CELL LPS-20kg

0₫

Mô tả

Xuất xứ: Trung Quốc

• Specification:

Maximum no. of intervals (n)	3000
Y = Emax/Vmin	6000
Zero balance	3 ±% of rated output
Compensated temperature range	-10 to +40 °C
Operating temperature range	-20 to +60 °C
Safe overload	150 % of R.C
Ultimate overload	200 % of R.C.
Excitation, recommended	10 Vdc or Vac rms
Excitation, maximum	15 Vdc or Vac rms
Insulation resistance	>5000 Mega-Ohms
Construction Anodized	Aluminum
Environmental protection	IP66
Standard capacities (Emax)	20kg
Non linearity	0.020 ±% of rated output
Hysteresis	0.020 ±% of rated output
Non-repeatability	0.020 ±% of rated output
Creep error (20 minutes)	0.017 ±% of rated output
Zero return (20 minutes)	0.017 ±% of rated output
Temperature effect on min. dead load output	0.014 ±% of rated output/°C
Temperature effect on sensitivity	0.008 ±% of applied load/°C
